Methane Cracking Educational Unit Operations Pilot Plant

Introduction

The Methane Cracking Educational Unit Operations Pilot Plant is an integrated, bench-scale teaching system designed for university laboratories to demonstrate catalytic hydrocarbon conversion, gas-phase chemical reactions, and process control. It provides engineering students with hands-on experience in high-temperature catalytic cracking, mass and heat transfer, and product gas management within a safe, controlled environment.

System Customization Options

To align with diverse curriculum structures and specific laboratory footprints, this pilot plant offers comprehensive customization. Both the hardware configurations—such as reactor geometries, sensor selections, and gas line additions—and the software control interfaces can be modified to meet the specific teaching and research requirements of your department.

Key Teaching Functions and Advantages

• Multi-Zone Thermal Control Practice: Hands-on study of temperature profiles along the catalyst bed using three-stage programmable heating up to 1000°C.
• Precision Gas-Phase Fluid Dynamics: Practical training in gas flow manipulation and mixing using integrated high-precision mass flow controllers.
• Real-time Process Automation: Direct exposure to industrial-style human-machine interfaces (HMI) with data logging and cloud-based monitoring.
• Industrial-Grade Safety Design: Comprehensive safety interlocks, including automated over-temperature and over-pressure shut-offs housed within a robust aluminum frame.
• Modular Catalyst Evaluation: Quick-disassembly fixed-bed reactor designed for rapid catalyst loading and comparative kinetic studies.

Detail & Parts

Technical Specifications and Curriculum Mapping

Academic Applications and Curriculum Integration

This pilot plant bridges the gap between theoretical calculations and practical process engineering. In Chemical Engineering, Environmental Engineering, and Energy/Fuel Technology programs, students often study complex concepts that are difficult to visualize in a standard lecture.

For instance, when studying Unit Operations of Chemical Engineering, the transport phenomena of high-temperature gases through packed beds become tangible realities on this unit. Similarly, in courses utilizing Transport Processes and Unit Operations (or Transport Processes and Separation Process Principles), students can analyze steady-state heat conduction across the multi-zone furnace and mass transfer during catalytic cracking.

Furthermore, the system serves as a physical reference for Chemical Engineering Design courses, demonstrating piping layouts, instrumentation symbols, and process safety barriers in action. By operating this pilot plant, students transition from reading about catalytic equations in reaction engineering textbooks to managing real-world reaction thermodynamics and mass balances.

Adaptable System Configurations

As teaching laboratories evolve, the flexibility of experimental equipment is critical. Both the software interface (including dashboard design and data communication protocols) and the physical hardware (including reactor material, gas feed lines, and analytical instrument integration) can be customized to suit your department's specific syllabus.
