Pressure Swing Adsorption Educational Unit Operations Pilot Plant
Item Number : LPK-BYXF
Price varies based on specs and customizations
- Adsorption Column Configuration
- Dual-column (A&B) with corrosion-resistant alloy for even gas distribution
- System Pressure Range
- Safe educational pressure swing ranges with robust digital pressure transmitters
- Control Interface
- Integrated industrial touch-screen panel with solenoid valve control and cycle timer settings
Shipping:
Contact us to get shipping details Enjoy On-time Dispatch Guarantee.
Why Choose Us
Easy ordering process, quality products, and dedicated support for your business success.
Product Overview
The Pressure Swing Adsorption Educational Unit Operations Pilot Plant is an integrated, bench-scale teaching system designed to introduce engineering students to the principles of gas separation and mass transfer. The unit focuses on the process of Pressure Swing Adsorption (PSA) for gas mixtures, specifically utilizing nitrogen-oxygen separation as a practical teaching model. By working directly with industrial-grade control interfaces and adjustable cycle configurations, students gain practical insight into how gas-solid separation processes are operated, monitored, and optimized in modern industrial plants.
To ensure that this equipment fits seamlessly into diverse teaching environments, the entire platform is highly customizable. LABPARK offers tailored modifications across both the hardware configurations (such as vessel sizing, alternative adsorbent column materials, and sensor selections) and the software control interfaces (including PLC programming, data logging capabilities, and user interface layouts) to meet the exact educational goals of your department.
Key Educational Functions & Advantages
- Industrial-Grade Process Control: Equipped with an integrated industrial touchscreen workstation, allowing students to interact with real-time process diagrams, monitor system pressures, and configure automated cycle sequences.
- Process Parameter Optimization: Students can program, test, and refine the cycle timelines (adsorption, equalization, depressurization, and regeneration) to observe direct impacts on product gas purity and recovery rates.
- Gas-Solid Separation Studies: The dual-column design enables continuous or semi-continuous cycle configurations, allowing comparison of different solid-phase adsorbents under varying pressure swing ranges.
- Comprehensive Digital Assessment Suite: The proprietary software includes a digital learning management system, enabling instructors to build question banks, generate exams, assign various question formats (multiple-choice, true/false), and automatically compile student scores.
Detail&Parts
Technical Specifications & Experimental Capabilities
| System Component / Parameter | Specification / Educational Function |
|---|---|
| Adsorption Column Assembly | Dual-column configuration (Column A & Column B) utilizing premium corrosion-resistant alloy, optimized for solid adsorbent packing and even gas distribution. |
| Gas Feed & Flow Control | Equipped with integrated flow meters and pressure regulators to manage and monitor feed air inlet conditions. |
| System Pressure Range | Designed for safe educational pressure swing ranges, utilizing robust pressure transmitters with digital readouts on the control panel. |
| Control Interface | Integrated industrial touch-screen panel with real-time process flow visualization, solenoid valve control, and cycle timer settings. |
| Gas Analysis Potential | Configurable for gas composition testing, allowing students to measure separation efficiency during nitrogen/oxygen production runs. |
| Auxiliary Equipment | Includes reliable pressure relief valves, buffer tanks for feed and product gases, and a quiet-running vacuum pump/compressor assembly. |
Curriculum Alignment & Core Textbook Integration
This educational pilot plant is designed to serve as a physical bridge between textbook theory and practical engineering application. By implementing hands-on experiments on this unit, instructors can demonstrate core transport phenomena and separation concepts found in standard engineering curricula.
The experimental operations map directly to fundamental concepts described in classic reference texts used in chemical, environmental, and process engineering programs worldwide:
| Classic Textbook Reference | Associated Unit Operations & Theoretical Concepts | Corresponding Experimental Module |
|---|---|---|
| Unit Operations of Chemical Engineering | Gas-solid separation processes, adsorption equilibrium isotherms, mass transfer zones, and bed regeneration dynamics. | Dynamic adsorption breakthrough curve determination and regeneration efficiency studies. |
| Transport Processes and Unit Operations | Mass transfer in packed beds, gas diffusion coefficients, and transient-state concentration profiles. | Evaluation of mass transfer resistance and concentration profiles across the dual adsorbent beds. |
| Chemical Engineering Design | Process instrumentation and control loops, cycle timing optimization, and vessel safety relief systems. | Programming PLC cycle times, optimizing purge-to-feed ratios, and testing pressure-swing sequencing. |
Hardware and Software Customization Services
Recognizing that every academic laboratory has unique spatial, pedagogical, and budgetary requirements, we prioritize flexibility in our manufacturing process. Our engineering team can customize both the software algorithms (such as data export formats and automated sequence templates) and the hardware components (including column dimensions, alternative gas feed connections, and sensor configurations) to align with your specific curriculum.
